| Connection Diameter Machine Side (DCONMS) | 4 mm | Usable Length (LU) | 12 mm |
| Minimum Bore Diameter (DMIN) | 4 mm | Shank Height (H) | 3.6 mm |
| Functional Length (LF) | 60 mm | Body Material | Carbide |
| Coating | TiN | Cutting Edge Material | Carbide |
| Grade | ZM3 | Measurement Type | Metric |
| Application | | Inserts for miniature | | Cutting Width (CW) | 0.75 mm |
| Cutting Depth Maximum (CDX) | 1.2 mm | Unit | M |
| Functional Width (WF) | 1.8 mm |
Product Features
| COO | Japan | BrandName | NTK |
| FamilyName | SBG Long type / Two-sided |
Shipping Info
Weight per item
0.0110
Name
Solid Boring Bars
FamilyName
SBG Long type / Two-sided
BrandName
NTK
